🍳 Cooking Timer App with Live Activities & Dynamic Island

This Flutter app integrates iOS Live Activities and Dynamic Island to display a real-time countdown timer for cooking dishes. The app uses the live_activities Flutter package to manage Live Activities and Dynamic Island features on iOS 16.1+ devices.

πŸ“– Blog Post

πŸ‘‰ Read the full guide on Medium

Read on Medium


πŸš€ Features

βœ… Live Activity Timer: Displays a cooking countdown timer in Dynamic Island & Lock Screen.
βœ… Real-Time Updates: Updates the remaining time every second.
βœ… Flutter & Swift Integration: Uses Dart for logic and Swift for Live Activity UI.
βœ… iOS 16.1+ Support: Works only on iPhones with iOS 16.1 or later.


Screenshot

Home Swipe Left Uncontacted Tab

πŸ“Œ Requirements

  • Flutter 3.x
  • Dart 3.x
  • Xcode (for iOS development)
  • iOS 16.1+ (Live Activities Support)

3️⃣ Live Activities Implementation

πŸ”Ή Dart Code (Start Cooking Timer)

import 'dart:async';
import 'package:live_activities/live_activities.dart';

final liveActivities = LiveActivities();
String? _activityId;
Timer? timer;

  @override
  void initState() {
    super.initState();

    super.initState();
    _initLiveActivities();
  }

  Future<void> _initLiveActivities() async {
    try {
      await liveActivities.init(appGroupId: "group.com.example.demoisland");
    } catch (e) {
      debugPrint("Error initializing Live Activities: $e");
    }
  }
 Future<void> _startCookingTimer() async {
    if (_dishNameController.text.isEmpty || _selectedMinutes == null) {
      ScaffoldMessenger.of(context).showSnackBar(
        const SnackBar(
            content: Text('Please enter dish name & select cooking time')),
      );
      return;
    }

    // Convert the selected minutes to seconds for the countdown
    double totalTimeInSeconds = (_selectedMinutes ?? 0) * 60;

    // Create the activity with the initial time
    final activityId = await liveActivities.createActivity({
      'dishname': _dishNameController.text,
      'endtime': totalTimeInSeconds, // Store time in seconds
    });

    setState(() {
      _activityId = activityId;
    });

    // Start the timer for the countdown
    timer = Timer.periodic(const Duration(seconds: 1), (timer) async {
      if (totalTimeInSeconds <= 0) {
        timer.cancel();
        _stopCookingTimer();
        // Stop the timer when time is up
      } else {
        totalTimeInSeconds -= 1; // Decrease by one second

        await liveActivities.updateActivity(_activityId ?? "", {
          'endtime': totalTimeInSeconds, // Update the remaining time
        });
      }
    });

    ScaffoldMessenger.of(context).showSnackBar(
      SnackBar(
        content:
            Text('🍳 Cooking timer started for ${_dishNameController.text}!'),
      ),
    );
  }

  Future<void> _stopCookingTimer() async {
    if (_activityId == null) {
      ScaffoldMessenger.of(context).showSnackBar(
        const SnackBar(content: Text('No active cooking timer')),
      );
      return;
    }

    await liveActivities.endActivity(_activityId!);

    setState(() {
      _activityId = null;
    });

    ScaffoldMessenger.of(context).showSnackBar(
      const SnackBar(content: Text('Cooking timer stopped! ⏹️')),
    );
  }

πŸ”Ή Swift Code (Live Activity Widget)

Modify DemoIslandiOS.swift:

import ActivityKit
import WidgetKit
import SwiftUI

struct LiveActivitiesAppAttributes: ActivityAttributes, Identifiable {
    public typealias LiveDeliveryData = ContentState

    public struct ContentState: Codable, Hashable {}

    var id = UUID()
}

struct  DemoIslandiOS: Widget {
    var body: some WidgetConfiguration {
        ActivityConfiguration(for: LiveActivitiesAppAttributes.self) { context in
            let remainingTime = context.state.remainingTime
            VStack {
                Text("🍳 Cooking: \(UserDefaults(suiteName: "group.com.example.myapp")!.string(forKey: "dishname") ?? "Unknown")")
                    .font(.title3)
                    .bold()
                    .foregroundColor(.white)
                Text("⏳ Remaining Time: \(formattedCountdown(from: remainingTime))")
                    .font(.headline)
                    .foregroundColor(.yellow)
            }
            .padding()
            .background(Color.black.opacity(0.8))
            .clipShape(RoundedRectangle(cornerRadius: 15))
        } dynamicIsland: { context in
            let remainingTime = context.state.remainingTime
            DynamicIsland {
                DynamicIslandExpandedRegion(.leading) {
                    Text("🍳 Cooking")
                }
                DynamicIslandExpandedRegion(.trailing) {
                    Text("\(formattedCountdown(from: remainingTime))")
                }
                DynamicIslandExpandedRegion(.bottom) {
                    Text("βŒ› Cooking in Progress... \(formattedCountdown(from: remainingTime))")
                        .font(.headline)
                        .foregroundColor(.yellow)
                }
            } compactLeading: {
                Text("🍳")
            } compactTrailing: {
                Text("\(formattedCountdown(from: remainingTime))")
            } minimal: {
                Text("⏳")
            }
        }
    }
}

// Function to format countdown time in MM:SS format
func formattedCountdown(from timeInterval: TimeInterval) -> String {
    let minutes = Int(timeInterval) / 60
    let seconds = Int(timeInterval) % 60
    return String(format: "%02d:%02d", minutes, seconds)
}

4️⃣ Flutter & Swift Integration

  • Flutter sends data to Swift using UserDefaults with the same App Group.
  • The Live Activity is updated every second in Swift using the data passed from Flutter.

🏁 Usage

To start the cooking timer, simply call the startCookingTimer() function:

This will:

  1. Start a Live Activity for the cooking timer.
  2. Update the Dynamic Island every second as the countdown decreases.

πŸ“ Notes

  • Live Activities and Dynamic Island are only available on devices with iOS 16.1 or later.

Here's the Markdown code for adding the troubleshooting section to your README.md file:

πŸ›  Troubleshooting Common Issues

While integrating Live Activities in Flutter, you may encounter the following errors. Here's how to fix them:

❌ 1. Cycle inside Runner; building could produce unreliable results.

πŸ” Error Message:

Cycle inside Runner; building could produce unreliable results. Cycle details:

βœ… Solution:

This issue happens due to build dependency cycles in Xcode. Follow these steps to fix it:

  1. Open Xcode and navigate to your project.
  2. Select Runner β†’ Build Phases.
  3. Move "Embed Foundation Extensions" above the "Run Script Build Phases" configuration.
  4. Clean the build folder:
    • Click Product β†’ Clean Build Folder (Shift + Cmd + K).
    • Run the following command in the terminal:
      flutter clean
  5. Rebuild the app:
    flutter pub get
    flutter build ios

πŸ“Έ Solution Screenshot Home

❌ 2. force_encoding': can't modify frozen String (FrozenError)

πŸ” Error Message:

force_encoding': can't modify frozen String (FrozenError)

βœ… Solution:

This error occurs because the Xcode project format. Set it to Xcode 16.0.
πŸ“Έ Solution Screenshot Home

πŸ’‘Still facing issues? Open an Issue in this repository

πŸ›  Development Tips

  • Ensure that both Flutter and Swift use the same App Group for sharing data.
  • Test on a physical device to view the Dynamic Island behavior.
  • Make sure to handle background execution and edge cases, such as when the app goes into the background.

πŸ”— Resources
